Facilities Equipment List
Machining Centers & Milling Machines
- (1) HERMLE C62 Mill Turn (Add “5 Axis” under capabilities) -
- X axis 47.24”
- Y axis 51.81
- Z axis 35.43”
- C axis 0- 360 Degree Rotary A axis +- 130 Degree Tilt 9000 RPM Spindle Milling 69 HP Turning 95 HP
- (1) MITSUBISHI MVR30 Bridge Mill
- 5-sided milling
- Y axis 110”
- X axis 165”
- Z axis 27”
- W axis 31”
- 60” under rail
- 99.5 through bridge
- 6000 RPM spindle
- Fanuc 18iMB control
- 1° right angle head indexing
- 55,000 table capacity
- (1) SHIBAURA BORING MILL BP-150.R22
- X axis 160"
- Y axis 120"
- 50 HP Spindle
- (2) DOOSAN DB130C HORIZONTAL BORING MILL (1 of these is set up for 5 axis. Add this under capabilities)
- X axis 118"
- Y axis 78"
- Z axis 62"
- W axis 27"
- Max table capacity 33,000 lbs.
- (1) TOSHIBA-CNC HORIZONTAL BORING MILL MODEL BTD-110.R16
- X axis of 98"
- Y axis of 59"
- Z axis of 57"
- W axis of 19"
- 55" x 63" full 4th axis rotary table
- Spindle dia. 4.3"
- 40 hp., with spring neck turning capability
- (2) MORI-SEIKI MH-63 HORIZONTAL MACHINING CENTERS
- Fanuc16M control
- Two 24.8" square rotary pallets with .001° minimum indexing capability
- 30 hp.
- 60-6,000 rpm
- Machining envelope of 39.4"
- X axis 33.5"
- Y axis and Z axis stroke of 36.2"
- (1) OKUMA MC-5VA VERTICAL MACHINING CENTER
- 15hp
- 30-4,000 rpm
- X axis of 41.3"
- Y axis of 20.1"
- Z axis of 22"
- (1) MATSURA MC-710V VERTICAL MACHINING CENTER
- Yasnac 3000G Control
- 7 HP
- 50-6,000 RPM
- X axis 28"
- Y axis 13.7"
- Z axis stroke 18.7"
- Work area 43.3" by 14.7"
- (1) NOMURA HORIZONTAL BORING MILL
- X axis of 40"
- Y axis of 40"
- Z axis of 32"
- W axis of 20"
- 35 3/8 by 39 3/8 rotary table
- Spindle diameter 3.35"
- (1) VIPER 2100 CNC MACHINING CENTER
- X axis 81"
- Y axis 41"
- Z axis 41"
- (1) SOUTHWESTEN TRAK DPM5X3 CNC BED MILL
